The Epa semi-absolute filters with galvanized steel frame are used in ventilation systems such as: Air Treatment units where semi-absolute terminal filtration is required; As a prefilter for absolute filters in Clean Rooms, Operating Theatres and Laboratories. Industrial Processes (Microelectronics Industry, Optics, Food Industry, Fine Chemistry, etc…)
Type: Semi-absolute Compact Filter.
Frame: Galvanized.
Filtering Element: Glass microfibre paper.
Separators: Thermoplastic glue beads.
Sealant: Polyurethane.
Gasket: Bicomponent polyurethane liquid system (Semi-circular expanded polyurethane).
MPPS efficiency: 85%
Class EN 1822: E10
Recommended Final Pressure Loss: 600 Pa.
Temperature: 80ºC in continuous service.
– The V-shaped pleating method guarantees an optimum geometry of the pleats and a uniform distance between them,
resulting in a lower pressure loss with a higher airflow.
– V-shaped pleating technology allows us to remove the aluminium separators and thereby eliminate the risk of
leaks due to the perforations of the aluminium separators.
– The filter is light and easy to eliminate thanks to the new manufacturing technology.
– The total use of the filtering area, in addition to the uniform dust deposition achieved through the new pleat shape
technology, leads to longer duration.
– Due to the increased filtering area, the speed of the air through the filter and the resistance to flow decrease, resulting in energy saving.
– Thanks to the uniform shape of the pleats the airflow does not generate turbulences.
– The Microven filters provide more protection and reliability as a result of the larger filtration area achieved by the new pleating
shape technology. Also filtration efficiency is improved and the cost-efficiency ratio is excellent.
– The filter media is self-extinguishing glass microfiber paper (class F-1) and resistant to humidity up to 100% relative humidity.
*UxP: Units per box
*Stock F: Manufacture, S: Stock, SL: Limited Stock
