Compact pocket filters

Multiven Standard 2V

Inlate, outlate and recirculation in ventilation systems requiring high security: air conditioning equipment, (air conditioning units, ventilation housings, etc.), air conditioning systems (office buildings, call centers, department stores, hospitals, museums and airports, etc.), industrial processes (pharmaceutical, food, optics, microelectronics, veterinary and chemical industry and surface treatments) and as a pre-filter for Hepa and Ulpa filters.

Technical features

Type: Compact Multihedral Rigid Bag Filter.
Frame: Plastic (Polystyrene).
Filtering Element: Fiberglass paper.
Separators: Thermoplastic glue beads.
Sealant: Polyurethane.
Average Efficiency % (Em): 60% ≤ Em < 80%, 80% ≤ Em < 90%, 90% ≤ Em < 95% and 95% ≤ Em.
EN 779 Class: M6, F7, F8 and F9.
ISO 16890: ePM10 65%, ePM1 50%, ePM1 60% and ePM1 75%.
Recommended Final Pressure Drop: 450 Pa.
Temperature: 80ºC continuous service.

Category

Air treatment

Certificates

Multiven Standard 2V
